826 Landfill Compactor

360° View

Product description

Cat landfill compactors are designed with durability built in, ensuring maximum availability through multiple lifecycles. With optimized performance and simplified serviceability, our machines allow you to operate more efficiently and safely. Introduced in 1978, the 826 has been an industry leader for over 45 years. Focused on helping our customers succeed, we have continued to build upon each new series. The 826 continues our legacy of reliability, performance, safety, operator comfort, serviceability, and efficiency.

Engine

Gross Power - SAE J1995:2014 - 435hp
Net Power - SAE J1349:2011 - 405hp
Net Power - ISO 9249:2007 - 405hp
Engine Power - ISO 14396:2002 - 426hp
Engine Model - C15 Cat®
Emissions - U.S. EPA Tier 4 Final/ EU Stage V/Korea Stage V and Japan 2014 or Brazil MAR-1, emitting equivalent to U.S. EPA Tier 3/EU Stage IIIA
Rated Speed - 1800
Torque Rise - 33%
Bore - 5.4in
Stroke - 6.7in
Displacement - 927.6in³
High Idle Speed - 2300r/min
Low Idle Speed - 800r/min
Maximum Altitude – Without Derating (Tier 4 Final/Stage V) - 9298ft
Maximum Altitude - Without Derating (Tier 3/Stage IIIA) - 9098ft
Note - Net power advertised is the power available at the engine flywheel when the engine is equipped with a fan, air cleaner, clean emissions module and alternator.

Operating Specifications

Operating Weight (Tier 4 Final/Stage V) - 90207lb
Operating Weight (Tier 3/Stage IIIA equivalent) - 89186lb
Maximum Operating Weight (Tier 4 Final/Stage V) - 92568lb
Maximum Operating Weight (Tier 3/Stage IIIA equivalent) - 91549lb

Transmission

Transmission Type - Planetary - Powershift - ECPC
Direct Drive - Forward 1 - 4.2mile/h
Direct Drive - Forward 2 - 7.5mile/h
Direct Drive - Reverse 1 - 4.3mile/h
Direct Drive - Reverse 2 - 8.6mile/h

Hydraulic System

Pump Flow at 1800 rpm - 30.9gal/min
Main Relief Pressure - 3771psi
Maximum Supply Pressure - 3495psi
Lift System - Double Acting Cylinder
Bore - 4.7in
Stroke - 42.1in

Service Refill Capacities

Cooling System - 30.6gal (US)
Engine Crankcase - 9gal (US)
Transmission - 17.4gal (US)
Fuel Tank - 206.6gal (US)
Diesel Exhaust Fluid Tank (Tier 4 Final/Stage V) - 8.5gal (US)
Differential - Final Drives - Front - 26.4gal (US)
Differential - Final Drives - Rear - 29.1gal (US)
Hydraulic Tank Only - 35.4gal (US)
Note - Cat diesel engines are required to use ULSD (ultra-low sulfur diesel fuel with 15 ppm of sulfur or less) or ULSD blended with the following lower-carbon intensity fuels** up to: • 20% biodiesel FAME (fatty acid methyl ester) * • 100% renewable diesel, H

Axles

Front - Planetary - Fixed
Rear - Planetary - Oscillating
Oscillation Angle - ±5°

Braking System

Service Brakes - Multi Disc Wet (Enclosed) 2 WHL
Parking Brake - Drum and Shoe, Spring Applied, Hydraulic Released

Sound Performance - Tier 4 Final / Stage V

Operator Sound Pressure Level (ISO 6396:2008) - 73dB(A)
Machine Sound Power Level (ISO 6395:2008) - 113dB(A)
Operator Sound Pressure Level (ISO 6396:2008)* - 72dB(A)
Machine Sound Power Level (ISO 6395:2008)* - 110dB(A)
Note (1) - * Sound suppression equipped
Note (2) - The machine sound power level was measured according to ISO 6395:2008. The measurement was conducted at 70 percent of the maximum engine cooling fan speed.
Note (3) - The operator sound pressure level was measured according to ISO 6396:2008. The measurement was conducted at 70 percent of the maximum engine cooling fan speed.
Note (4) - Hearing protection may be needed when the machine is operated with a cab that is not properly maintained or when the doors or windows are open for extended periods or in a noisy environment.

Sound Performance - Tier 3 / Stage IIIA

Operator Sound Pressure Level (ISO 6396:2008) - 73dB(A)
Machine Sound Power Level (ISO 6395:2008) - 113dB(A)
Operator Sound Pressure Level (ISO 6396:2008)* - 72dB(A)
Machine Sound Power Level (ISO 6395:2008)* - 110dB(A)
Note (1) - * Sound suppression equipped
Note (2) - The machine sound power level was measured according to ISO 6395:2008. The measurement was conducted at 70 percent of the maximum engine cooling fan speed.
Note (3) - The operator sound pressure level was measured according to ISO 6396:2008. The measurement was conducted at 70 percent of the maximum engine cooling fan speed.
Note (4) - Hearing protection may be needed when the machine is operated with a cab that is not properly maintained or when the doors or windows are open for extended periods or in a noisy environment.

Hydraulic System - Steering

Steering System - Circuit - Pilot operated, load sensing
Bore - 4.5in
Stroke - 22.7in
Steering System - Pump - Piston - Variable Displacement
Maximum System Flow - 170 L/min @ 1,800 rpm (44.9 gal/min @ 1,800 rpm)
Steering Pressure Limited - 3481psi
Vehicle Articulation Angle - 86°

Dimensions (Approximate)

Height to Top of Air Conditioning Condenser - 14.99ft
Height - Cab Roof - 13.75ft
Height - Top of Beacon - 15.63ft
Height - Top of Exhaust Pipe - 14.56ft
Height - Top of Hood - 10.87ft
Ground Clearance - Bumper - 3.15ft
Centerline of Rear Axle to Edge of Counterweight - No Rear Radiator Guard - 9.38ft
Centerline of Rear Axle to Edge of Counterweight - Including Rear Radiator Guard - 10.16ft
Hitch to Centerline of Front Axle - 6.07ft
Wheel Base - 12.14ft
Length - With Blade on Ground - Straight Blade - Including Rear Radiator Guard - 28.59ft
Ground Clearance - 2.11ft
Width - Over Wheels - 12.47ft
Turning Radius - Inside of Wheels - 9.18ft

Straight Blade

Width – Moldboard Length - 14.16ft
Width - Over End Bits - 14.75ft
Height with Cutting Edge and Screen - 6.23ft
Maximum Depth of Cut - 1.5ft
Maximum Lift above Ground - 4.19ft
Capacity, Rated - 16.1yd³
Overall Machine Length (includes rear radiator guard, measured to cutting edge) - 28.59ft

Semi U-Blade

Width – Moldboard Length - 14.66ft
Width - Over End Bits - 14.83ft
Height with Cutting Edge and Screen - 6.63ft
Maximum Depth of Cut - 2.03ft
Maximum Lift above Ground - 3.825ft
Capacity, Rated - 20.9yd³
Overall Machine Length (includes rear radiator guard, measured to cutting edge) - 29.54ft

U-Blade

Width – Moldboard Length - 14.25ft
Width - Over End Bits - 14.41ft
Height with Cutting Edge and Screen - 6.62ft
Maximum Depth of Cut - 2.03mm
Maximum Lift above Ground - 3.79ft
Capacity, Rated - 22.9yd³
Overall Machine Length (includes rear radiator guard, measured to cutting edge) - 30.7ft

Wheels

Combination Tips (Weight Group) - 21125lb
Plus Tips - Weight (Group) - 22002lb
Paddle Tips - Weight (Group) - 20540lb
Diamond Tips Weight (Group) - 23997lb
Outside Diameter - 77.6in
Outside Diameter - Diamond - 78.1in
Drum Diameter - 63.4in
Drum Width - 47.2in
Feet Per Row - 6
Feet Per Wheel - 30
Replaceable - Weld On
Width Over Drums - 3800mm
Tip Height - 179mm
Tip Height - Diamond - 7.25in

Standard Equipment:

Note
- Standard and optional equipment may vary. Consult your Cat dealer for details.
Powertrain
- Single Clutch Speed Shifting (SCSS)
- Electronic Clutch Pressure Control (ECPC)
- Air-to-air aftercooler
- Brakes, full hydraulic, enclosed, wet multiple disc service brakes
- Cat Clean Emission Module (U.S. EPA Tier 4 Final/ EU Stage V only)
- Muffler (under hood) (U.S. EPA Tier 3/EU Stage IIIA equivalent)
- Electro-hydraulic parking brake
- Engine, Cat C15 configured for two emissions options: Tier 4 Final/Stage V, or emitting equivalent to Tier 3/Stage IIIA
- Fuel priming pump (electric)
- Fuel-to-air cooler
- Ground level engine shutdown
- Heat shield, turbo and exhaust manifold
- Hydraulically driven demand fan
- Integrated braking system
- Radiator, Aluminum Modular (AMR)
- Separated cooling system
- Starting aid (ether)
- Throttle lock
- Torque converter with Lock Up Clutch (LUC)
- Eco Mode
- Transmission, planetary, with 2F/2R speed range control
- Under hood ventilation system
Electrical
- Alarm, back-up
- Alternator, 150 amp
- Batteries, maintenance-free (4 - 1,000 CCA)
- Electrical system, 24V
- Light, warning unswitched (LED strobe)
- Lighting system, halogen (front and rear)
- Lighting, access stairway
- Lighting, underhood
- Starter, electric (heavy duty)
- Ground level lockable master disconnect switch
- Auxiliary start receptacle
Operator Environment
- Camera, rear vision
- Air conditioner with roof-mounted condenser
- Cab, sound-suppressed pressurized
- Internal four-post rollover protective structure (ROPS/FOPS)
- Radio ready for entertainment: – Antenna – Speakers – Converter (12V, 10-15 amp)
- 12V power port for mobile phone or laptop connection
- Radio, CB ready
- Coat and hard hat hooks
- Fingertip shifting controls
- Flip-up armrest
- Heater and defroster
- Implement hydraulic lockout
- Glass (window) - rubber mounted glass
- Light, (dome) cab
- Lunch box and beverage holders
- Instrumentation, gauges: – Diesel exhaust fluid (DEF) level (U.S. EPA Tier 4 Final/ EU Stage V) – Engine coolant temperature – Fuel level – Hydraulic oil temperature – Speedometer/tachometer – Torque converter temperature
- Instrumentation, warning indicators: – Action alert system, three categories – Brake oil pressure – Electrical system, low voltage – Engine failure malfunction alert and action lamp – Parking brake status
- Mirror, internal (panoramic)
- Mirrors, heated, rearview (externally mounted)
- Premium plus seat containing forced air heating and cooling, 2-way thigh adjustment, power lumbar and back bolster adjustment, ride stiffness adjustment, dynamic end dampening, and leather finish
- Seat belt with minder, retractable, 76 mm (3 in) wide
- Steering and Transmission Integrated Control (STIC^™) system with lockout
- Sun visor, front
- Tinted glass
- Transmission gear (indicator)
- Vital Information Management System (VIMS^™): – Graphical information display – External data port – Customizable operator profiles
- Wet-arm wipers/washers (front and rear)
- Intermittent wipers (front and rear)
- Precleaner, cab powered
- Horn group (trumpet)
Guards
- Guards, axle (front and rear)
- Guard, cab window
- Guard, driveshaft
- Guards, crankcase and powertrain, hydraulically powered
- Guard, differential (front and rear)
Fluids
- Antifreeze, premixed 50% concentration extended life (–34° C/–29° F)
Other Standard Equipment
- Demand fan/swing out (hydraulic reversible)
- Doors, service access (locking)
- Ecology drains for engine, radiator, transmission, hydraulic tank
- Emergency platform exit
- Engine, crankcase, 500 hour interval with CJ-4 oil
- Engine idle management features: – Auto idle kickdown – Delayed engine shutdown – Engine idle shutdown
- Fire suppression ready
- Fuel tank, 782 L (207 gal)
- Hitch, drawbar with pin
- Hoses, Cat XT^™
- Hydraulic, engine, and transmission oil coolers
- Total hydraulic filtration system
- Oil sampling valves
- Oil change system, high speed
- Steering, load sensing
- Stairway, left and right rear access
- Vandalism protection caplocks
- Venturi stack
- Fold-down exhaust stack for shipping
Technology Products
- Product Link^™ – Cellular, Satellite
Special Arrangements
- Engine: – Sound suppression
- Engine precleaners - single stage
Blades
- Dozer arrangement (no blade)
Wheels And Cleaner Bars
- Striker bars
- Wheels and tips: wheel arrangements – 7" combination tips

Optional Equipment:

Note
- Standard and optional equipment may vary. Consult your Cat dealer for details.
Operator Environment
- Radio, AM/FM/Aux/USB/Bluetooth^®
- Cat Compact SBAS Mapping (available through SITECH only)
- Cat Compact RTK Mapping (available through SITECH only)
Guards
- Guard – rear fan and grill
Powertrain
- Heater, engine coolant, 120V
- Heater, engine coolant, 240V
Special Arrangements
- Engine precleaners – dual stage
Miscellaneous
- CE/UKCA Certification (standard where regulations require it)
- Plate – year of manufacture (Tier 3/Stage IIIA equivalent only)
Wheels And Cleaner Bars
- Striker bars with cleaner fingers
Other Standard Equipment
- Stairway, swingout (LH & RH)
